12mm 200m Underground FRP Duct Rodder
  • 12mm 200m Underground FRP Duct Rodder

12mm 200m Underground FRP Duct Rodder

Short Description:


  • MOQ:
  • Package:
  • Brand:
  • Payment terms:
  • Shipping way:
  • :

    • Product Detail

    Duct Rodder inner packed by plastic woven strip,outer can be packed by wooden box or carton.Local pick up from factory ,or we can arrange delivery to your place.

    How to use:
    1. The glass rod is made of steel coated lead wheel leads, and then the corresponding metal joint, through the pipeline.
    2. When used to clean up the head to drive the cleaning tool, you can clean up the pipeline.
    3. When the cable is used, the wire or wire can be brought into the wire, and then wire or cable is used to pull the cable into the pipe.



    Specification

    Rod Diameter(mm)

    Φ4.5, Φ6, Φ8, Φ9, Φ10, Φ11, Φ12, Φ13, Φ14, Φ15, Φ16,Φ18

    Rod Length(m)

    30m~500 m

    Frame Spec.(mm)

    1300x450x1330, 1200x420x1220, 980x350x1000, 680x240x700, 420x180x400

    Material

    Fiberglass Rod Inner

    Extruded fiberglass and high strength resin at high temperature

    Fiberglass Rod Cover

    UV-resistant pp cover

    Metal Frame

    Galvanized steel tube

    PhysicalProperty

    Fiberglass Content

    75-80%

    Density

    >1.9 gr/cm3

    Working Environment

    -40°C to+80°C

    Minimum Pulling Strength

    4000N+/-5%

    Rod Consistency

    137 gr/m

    Flexural Modulus

    >46.500 Mpa

    Elongation at Break

    2.5-3%

    Min Bending Radius

    388 mm

    Any questions, please contact us via trade message or email us.

    We will reply your message within 24 hours.

    We will always do our up most to exceed your expectations in customer service,communication and dispatching of your orders.
